7. Place the carrier on a padded static-safe surface and loosen the card lock screws.
The screws are on the back of the carrier (
FIGURE 3-4
Figure Legend
1
8. Turn the carrier over and remove the dummy card or PCI card.
9. For very small PCI cards (1.25 in./31 mm tall or 3.0 in./76 mm wide), it is
necessary to do one or both of the following:
Move the long card lock (type B lock) from the horizontal slider slot to the front
■
vertical slider slot, then slide it down to reach the top of the PCI card.
Rotate the small card lock (type C lock) and slide it to the rear edge of the PCI
■
card.
See
10. Place the PCI card on the carrier.
a. Place the front of the card inside the housing (
3-4
External I/O Expansion Unit Installation and Service Manual for SPARC Enterprise T5xxx Servers • April 2011
Screws for Card Locks
1
Card lock screws
and
FIGURE 1-19
FIGURE 1-20
).
FIGURE 3-4
for examples.
FIGURE 3-5
).
