Using Card Locks With Low and Very Low Height PCI Cards

Lock Arrangements for Low and Very Low Height PCI cards
FIGURE 1-19
1
2
Figure Legend
1 Low height card
2 Very low height card
2 type A on top, 1 type A on right side, 1 type C on lower right side of the PCI card
1 type B on top, 1 type A on right edge, 1 type C on lower right side of the PCI card
