Chapter 3
Table 3-6. USB0 and USB1 Interface Pin Signals (J12) (Continued)
9 USB_GND0
10 USB_GND1
Note: The shaded table cells denote power or ground.
Table 3-7 describes the pin signals of the USB2 and USB3 header, which consists of 10 pins in two rows,
with odd/even (1, 2) pin sequence, and 0.079" (2mm) pitch.

Table 3-7. USB2 and USB3 Interface Pin Signals (J14)

Pin # Signal
1 USB-PWR_2
2 USB-PWR_3
3 CONN_USB2_N
4 CONN_USB3_N
5 CONN_USB2_P
6 CONN_USB3_P
7 USB_GND2
8 USB_GND3
9 USB_GND2
10 USB_GND3
Note: The shaded table cells denote power or ground.
Table 3-8 describes the pin signals of the USB4 and USB5 header, which consists of 10 pins in two rows,
with odd/even (1, 2) pin sequence, and 0.079" (2mm) pitch.

Table 3-8. USB4 and USB5 Interface Pin Signals (J13)

Pin # Signal
1 USB-PWR_4
2 USB-PWR_5
3 CONN_USB4_N
4 CONN_USB5_N
5 CONN_USB4_P
6 CONN_USB5_P
7 USB_GND4
8 USB_GND5
9 USB_GND4
10 USB_GND5
Note: The shaded table cells denote power or ground.
CoreModule 720
USB0 Ground
USB1 Ground
Description
USB2 Power – VCC (+5V +/-5%) power goes to the port through an on
board fuse. Port is disabled if this input is low.
USB3 Power – VCC (+5V +/-5%) power goes to the port through an on
board fuse. Port is disabled if this input is low.
USB2 Port Data Negative
USB3 Port Data Negative
USB2 Port Data Positive
USB3 Port Data Positive
USB2 Ground
USB3 Ground
USB2 Ground
USB3 Ground
Description
USB4 Power – VCC (+5V +/-5%) power goes to the port through an on
board fuse. Port is disabled if this input is low.
USB5 Power – VCC (+5V +/-5%) power goes to the port through an on
board fuse. Port is disabled if this input is low.
USB4 Port Data Negative
USB5 Port Data Negative
USB4 Port Data Positive
USB5 Port Data Positive
USB4 Ground
USB5 Ground
USB4 Ground
USB5 Ground
Reference Manual
Hardware
25
