Chapter 2

Module Features

CPU
Provides a 600MHz, 1.3GHz, or 1.6GHz Intel Atom E620T, E660T, or E680T Processor Core and
Graphics Memory Controller Hub
Provides Enhanced SpeedStep® technology
Supports Hyper-Threading Technology
Provides on-die 512-kB, 8-way L2 cache
Provides L2 Dynamic Cache Sizing
Supports 32-bit physical addresses and 48-bit linear addresses
Provides 3D graphics engine
Provides single-channel DDR2 memory controller
Memory
Provides up to 2 GB of +1.8V DDR2 soldered, on-board memory
Provides double data rate interface
Supports 32-bit data bus
Supports DDR2 800MHz memory
Provides non-ECC, unbuffered memory
Expansion Buses
PC/104 bus speeds up to 14MHz (16-bit ISA Bus)
PC/104-Plus bus speed at up to 66MHz (32-bit PCI Bus)
PCI 3.0 bus
I2C 2.1 bus
Bosch CAN protocol version 2.0B Active
SATA Interface
Supports two SATA ports from the EG20T PCH (one used for SSD)
Provides one standard SATA connector
Supports on-board Solid State Drive (SSD) with default 8GB capacity
Serial Interface
Provides four buffered serial ports (COM0-3), with full handshaking on the COM0 port
Provides 16550-equivalent controllers with 256-byte FIFO mode on the COM0 port
and 64-byte FIFO mode on the COM1-3 ports
Supports full-duplex buffering and full status reporting
Supports full modem capability on COM0 port
Supports programmable baud-rate generator
COM0: 300bps to 4Mbps
COM1, 2, and 3: 300bps to 1Mbps
CAN Interface
Supports bit rate up to 1 Mbps
Supports 32 message objects
CoreModule 720
Reference Manual
Product Overview
5
