2.8 Power Specifications

Input Power: AT mode and ATX mode
Power Management: ACPI 3.0 compliant with battery support
Power States: supports S0, S1, S3, S4, S5
Test Configuration
Function
Memory
Graphics
Hard Drive
Backplane
Power Supply
Intel
®
Atom™ Processor N2600 1.66Gz, (1MB L2 cache, 3.5W)
Power State
Windows 7 logon screen (idle)
Max. Load (Intel Power Utility Tool)
S5 Mode (soft off)
S3 Mode (suspend to RAM)
Intel
®
Atom™ Processor N2800 1.86Gz, (1MB L2 cache, 6.5W)
Power State
Windows 7 logon screen (idle)
Max. Load (Intel Power Utility Tool)
S5 Mode (soft off)
S3 Mode (suspend to RAM)
®
Intel
Atom™ Processor D2550 1.86GHz, (1MB L2 cache, 10 W)
Power State
Windows 7 logon screen (idle)
Max. Load (Intel Power Utility Tool)
S5 Mode (soft off)
S3 Mode (suspend to RAM)
Page 10
Configuration
Transcend 4GB DDR3 1333 SODIMM (I) (SEC 107 HCH9K4B260846C)
Intel® Atom® N2000/D2000 Series Embedded Media and Graphics Driver
Seagate ST320LT020 MomentusThin 320G
ETX-Proto B3
FSP FSP350-60PFG 350W
Power Requirement
Current
+5V (4.88V)
1.29A
+5V (4.86V)
2.04A
5V Standby
0.06A
5V Standby
0.07A
Power Requirement
Current
+5V (4.82V)
1.52A
+5V (4.80V)
2.83A
5V Standby
0.07A
5V Standby
0.09A
Power Requirement
Current
+5V (4.88V)
1.78A
+5V (4.84V)
2.89A
5V Standby
0.057A
5V Standby
0.09A
ETX-CV User's Manual
Power
6.30W
9.91W
0.30W
0.35W
Power
7.33W
13.58W
0.35W
0.45W
Power
8.69W
13.99W
0.29W
0.45W
