Chapter 2

Mechanical Specifications

3.55 (90.17mm)
3.35 (85.09mm)
0.20 (5.08mm)
0.00
0.50 (12.70mm)
NOTE
All dimensions are given in inches. Black square pins on headers and connectors
represent pin 1. Black square pins on right-angle headers represent pin 2 in top-side
views and pin 1 in bottom-side views.
CoreModule 720

Figure 2-8. Mechanical Overview (Top Side)

Reference Manual
Product Overview
4.05 (102.87mm)
3.55 (90.17mm)
3.20 (81.28mm)
1.38 (35.05mm)
0.30 (7.62mm)
0.00
0.50 (12.70mm)
15
