Chapter 2
NOTE
The pinout tables in Chapter 3 of this manual identify pin sequence using the
following method: A 10-pin header with two rows of pins, using odd/even
numbering, where pin 2 is directly across from pin 1, is noted as 10-pin, 2 rows, odd/
even (1, 2). See
Key:
J1 - LPC
J3 - GPIO
J4 - CAN
J5 - SD Memory Socket - Bottom
J6 - I2C
J7 - SATA0
J8 - Ethernet - Gigabit
J9 - Ethernet LED - Gigabit
J10 - Serial 1 - COM 0
J11 - Serial 2 - COM 1, 2, 3
J12 - USB 0, 1
J13 - USB 4, 5
J14 - USB 2, 3
J15 - SDVO
J17 - PC/104-Plus
J18 - PC/104
J19 - Power
J20 - Battery
J21 - Fan
J22 - Utility
J23 - LVDS
J24 - SMBus
JP1 - RTC Reset
(See jumper table)
JP3 - LVDS Voltage Select
(See jumper table)
JP1

Figure 2-6. Header, Connector, and Socket Locations (Top Side)

NOTE
Black square pins on headers and connectors represent pin 1. Black square pins on
right-angle headers represent pin 2 in top-side views and pin 1 in bottom-side views.
12
Figure
2-5.
10-pin, two rows,
Odd/Even, (1, 2)

Figure 2-5. Connector Pin Sequences

J1
J15
J9
AB
J19
DC
J18
J3
J20
J13
Reference Manual
9
5
3
1
7
10
8
6
4
2
J8
J23
JP3
J7
J14
J12
J11
J10
Product Overview
J21
ABCD
J17
J6
J22
J24
J4
CoreModule 720
