Chapter 4
GPIO Configuration
GPIO 0 [Disabled; Enabled]
GPIO 1 [Disabled; Enabled]
GPIO 2 [Disabled; Enabled]
GPIO 3 [Disabled; Enabled]
GPIO 4 [Disabled; Enabled]
GPIO 5 [Disabled; Enabled]
GPIO 6 [Disabled; Enabled]
GPIO 7 [Disabled; Enabled]
GPIO 8 [Disabled; Enabled]
GPIO 9 [Disabled; Enabled]
GPIO 10 [Disabled; Enabled]
GPIO 11 [Disabled; Enabled]
Thermal Configuration
Critical Trip Point [POR; 30 C; 40 C; 50 C; 60 C; 70 C; 80 C; 90 C; 95 C]
Active Trip Point [Disabled; 30 C; 40 C; 50 C; 60 C; 70 C; 80 C; 90 C; 95 C; 100 C]
Passive Trip Point [Disabled; 30 C; 40 C; 50 C; 60 C; 70 C; 80 C; 90 C; 95 C; 100 C]
Passive TC1 Value [1]
Passive TC2 Value [5]
Passive TSP Value [10]
Thermal Offset [Disabled; Enabled]
DTS Calibration [Disabled; Enabled]
SDIO Configuration
SDIO Access Mode [Auto; DMA; PIO]
USB Configuration
USB Devices:
1 Keyboard
Legacy USB Support [Disabled; Enabled]
EHCI Hand-off [Disabled; Enabled]
USB hardware delays and time-outs:
USB transfer time-out [1 sec; 5 sec; 10 sec; 20 sec]
Device reset time-out [10 sec; 20 sec; 30 sec; 40 sec]
Device power-up delay [Auto; Manual]
ADM1032 H/W Monitor
CPU Health Status
CPU Temp
Serial Port Console Redirection
COM0 (Pci Bus2, Dev10, Func1)
Console Redirection [Disabled; Enabled]
40
: +XX
Reference Manual
BIOS Setup
CoreModule 720
