Boot Bios Setup Screen; Figure 4-4. Boot Bios Setup Screen - ADLINK Technology CoreModule 720 Reference Manual

Chapter 4

Boot BIOS Setup Screen

Main Advanced
Boot Configuration
Quiet Boot
Fast Boot
Setup Prompt Timeout
Bootup NumLock State
CSM16 Module Version
GateA20 Active
Option ROM Messages
Interrupt 19 Capture
WatchDog Timer
Boot Option Priorities
Boot Option #1
Boot Option #2
Hard Drive BBS Priorities
•
Boot Configuration
Quiet Boot [Disabled; Enabled]
♦
Fast Boot [Disabled; Enabled]
♦
Setup Prompt Timeout
♦
Bootup NumLock State [On; Off]
♦
•
CSM16 Module Version XX.XX
Gate A20 Active [Upon Request; Always]
♦
Option ROM Messages [Force BIOS; Keep Current]
♦
Interrupt 19 Capture [Disabled; Enabled]
♦
WatchDog Timer [0]
♦
•
Boot Option Priorities
Boot Option #1 [P1-GLS85LS1032A CS 32GBN A101C0; Built -in EFI Shell; Disabled]
♦
Boot Option #2 [P1-GLS85LS1032A CS 32GBN A101C0; Built-in EFI Shell; Disabled]
♦
Hard Drive BBS Priorities
♦
• Boot Option #1 [P1-GLS85LS1032A CS 32GBN A101C0; Disabled]
CoreModule 720
Aptio Setup Utility - Copyright (C) 20XX Amreican Megatrends, Inc.
Chipset Boot
[Enabled]
[Disabled]
1
[On]
XX.XX
[Upon Request]
[Force BIOS]
[Disabled]
0
[P1-GLS85LS1032A CS. . .]
[Built-in EFI Shell]
Version X.XX.XXXX. Copyright (C) 20XX American Megatrends, Inc.

Figure 4-4. Boot BIOS Setup Screen

[1]
Reference Manual
Security Save & Exit
[Setting Description]
: Select Screen
: Select Item
Enter : Select
+/- : Change Opt.
F1 : General Help
F2 : Previous Values
F3 : Optimized Defaults
F4 : Save & Exit
ESC: Exit
BIOS Setup
43
