Chapter 3

Overview

This chapter discusses the chips and connectors of the module features in the following order:
CPU
Graphics
Memory
Interrupt Channel Assignments
Memory Map
I/O Address Map
Serial Port Interfaces
USB Interfaces
Ethernet Interface
Video Interfaces
LVDS
SDVO
Power Interface
GPIO Interface
Utility Interface
Power Button
Reset Switch
Speaker
SMBus Interface
CAN (Controller Area Network) Interface
2
I
C Interface
System Fan Interface
Battery Interface
Ethernet LED Interface
Miscellaneous
SSD (SATA Solid State Drive)
Time of Day/RTC
Oops! Jumper (BIOS Recovery)
Serial Console
Hot Cable
Watchdog Timer
CoreModule 720
Hardware
Reference Manual
19
