Chapter 3

Video (SDVO/LVDS) Interfaces

The Atom™ E6XXT CPU provides an integrated 2D/3D graphics engine, which supports video decode such
as MPEG2, MPEG4, VC1, WMV9, H.264 (main, baseline at L3 and High-profile level 4.0/4.1), and DivX*
as well as video encode such as MPEG4, H.264 (baseline at L3), and VGA. The CPU supports LVDS and
SDVO display ports, permitting simultaneous, independent operation of two displays. The video interface
features are listed in the following bullets. Refer to
Table 3-11
for the LVDS pin signal definitions.
SDVO:
Supports a maximum resolution of 1280 x 1024 at 85Hz (pixel clock rate up to 160MHz)
Supports a single channel interface through a 30-pin FPC connector
Supports 100MHz to 160MHz derivative clock frequency
Supports third-party output formats such as DVI, LVDS, HDMI, TV-Out, and VGA
Provides a control bus able to operate at up to 1 MHz
LVDS:
Supports a maximum resolution of 1280 x 768 at 60Hz (pixel clock rate up to 80MHz)
Supports minimum pixel clock rate of 19.75MHz
Supports a single channel interface through a 20-pin header
Supports pixel color depths of 18 and 24 bits
Supports 20MHz to 80MHz derivative clock frequency
Table 3-10
lists the pin signals of the SDVO FPC connector, which provides 30 pins in a single row with
0.020" (0.5mm) pitch.

Table 3-10. SDVO Interface Pin Signals (J15)

Pin #
Signal
1
GND1
2
SDVOB_CLK-
3
SDVOB_CLK+
4
GND2
5
SDVOB_GREEN-
6
SDVOB_GREEN+
7
GND3
8
SDVOB_INT-
9
SDVOB_INT+
10
GND4
11
SDVOB_BLU-
12
SDVOB_BLU+
13
GND5
14
SDVOB_RED-
15
SDVOB_RED+
16
GND6
17
SDVO_FLDSTALL-
18
SDVO_FLDSTALL+
19
GND7
CoreModule 720
Table 3-10
for definitions of the SDVO pin signals and
Description
Ground 1
SDVO B Clock Negative
SDVO B Clock Positive
Ground 2
SDVO B GREEN Negative
SDVO B GREEN Positive
Ground 3
SDVO B Input Interrupt Negative
SDVO B Input Interrupt Positive
Ground 4
SDVO B BLUE Negative
SDVO B BLUE Positive
Ground 5
SDVO B RED Negative
SDVO B RED Positive
Ground 6
SDVO Input Field Stall Negative
SDVO Input Field Stall Positive
Ground 7
Reference Manual
Hardware
27
