Chapter 4
•
vBIOS Version
•
IEGD Driver Version
IGD Mode Select [Disabled;
♦
MSAC Mode Select [Enabled, 512MB;
♦
Boot Display Configuration
♦
•
Boot Display Device [Integrated LVDS; External DVI/HDMI]
•
Flat Panel Scaling [Auto; Forced; Disabled]
•
Flat Panel Type [640x480 18bit;
•
South Bridge Chipset Configuration
SMBUS Controller [Enabled; Disabled]
♦
High Precision Event Timer Configuration
♦
•
High Precision Timer [Disabled; Enabled]
PPM Config
♦
•
C-state POPUP [Disabled; Enabled]
42
XXXX
N/A
Enabled, 1MB;
Enabled, 4MB;
Enabled, 8MB;
Enabled, 16MB;
Enabled, 32MB;
Enabled, 48MB;
Enabled, 64MB]
Enabled, 256MB;
Enabled, 128MB]
800x600 18bit;
1024x600 18bit;
1024x768 18bit;
1280x768 18bit;
640x480 24bit;
800x600 24bit;
1024x600 24bit;
1024x768 24bit;
1280x768 24bit]
Reference Manual
BIOS Setup
CoreModule 720
