Chapter 2
USB Interface
Provides three root USB hubs
Provides up to six USB ports
Supports USB boot devices
Supports USB Keyboard and Mouse
Supports USB v2.0 EHCI and v1.1 UHCI
Supports over-current detection status
Ethernet Interface
Provides one fully independent Ethernet port
Provides integrated LEDs on each port (Link/Activity and Speed)
Provides one Intel 82574IT controller chip
Provides header for LAN LED signals (Gigabit only)
Supports IEEE 802.3 10/100BaseT and 10/100/1000BaseT compatible physical layers
Supports Auto-negotiation for speed, duplex mode, and flow control
Supports full duplex or half-duplex mode
Full-duplex mode supports transmit and receive frames simultaneously
Supports IEEE 802.3x Flow control in full duplex mode
Half-duplex mode supports enhanced proprietary collision reduction mode
Video Interfaces (SDVO and LVDS)
Provide SDVO outputs
Resolutions up to 1280x1024 @ 85Hz
A variety of external display technologies such as DVI, TV-Out, and CRT
Maximum pixel clock rate up to 160MHz
Provide LVDS flat panel outputs
Resolutions up to 1280x768 @ 60Hz
Minimum pixel clock rate of 19.75MHz
Maximum pixel clock rate of 80MHz
Pixel color depths of 18 and 24 bits
Utility Interface
Power Button
Reset Switch
Speaker
Miscellaneous
Real Time Clock (RTC) with external replaceable battery
Battery-free boot
Oops! Jumper support
Serial Console support
Watchdog Timer
Logo Screen (Splash)
6
Reference Manual
Product Overview
CoreModule 720
