Chapter 4
Console Redirection Settings
- Terminal Type [VT100; VT100+; VT-UTF8; ANSI]
- Bits per second [9600; 19200; 38400; 57600; 115200]
- Data Bits [7; 8]
- Parity [None; Even; Odd; Mark; Space]
- Stop Bits [1; 2]
- Flow Control [None; Hardware RTS/CTS]
- Recorder Mode [Disabled; Enabled]
- Resolution 100x31 [Disabled; Enabled]
- Legacy OS Redirection [80x24; 80x25]
.
NOTE
The serial port console is not hardware protected. Diagnostic software that
probes hardware addresses may cause a loss or failure of the serial console
functions.

Chipset BIOS Setup Screen

Main
Advanced
North Bridge Chipset Configuration
South Bridge Chipset Configuration
North Bridge Chipset Configuration
Memory Information
MRC Version
Total Memory
CoreModule 720
Aptio Setup Utility - Copyright (C) 20XX American Megatrends, Inc.
Chipset
Boot
Version X.XX.XXXX. Copyright (C) 20XX American Megatrends, Inc.

Figure 4-3. Chipset BIOS Setup Screen

Reference Manual
Security
Save & Exit
[Setting Description]
:
:
Enter : Select
+/- : Change Opt.
F1 :
General Help
F2 :
Previous Values
F3 :
Optimized Defaults
F4 :
Save & Exit
ESC: Exit
XX.XX
XXXX MB (DDR2)
BIOS Setup
Select Screen
Select Item
