Chapter 2

Specifications

Physical Specifications

Table 2-4
provides the physical dimensions of the CoreModule 720.

Table 2-4. Weight and Footprint Dimensions

Item
Dimension
Weight
0.12 kg (0.25 lbs)
Height (overall)
11.05 mm (0.435 inches)
Board thickness
2.362 mm (0.093 inches)
Width
96.01 mm (3.78 inches)
Length
115.57 mm (4.55 inches)
14
NOTE
Height is measured from the upper
board surface to the highest permanent
component (PC/104 connector) on the
upper board surface. This does not
include the heatsink, which is required
on all versions of the board but does not
increase the height of the board.
Component height should not exceed
0.345" (8.763mm) from the upper
surface of the board and 0.190"
(4.826mm) from the lower surface of the
board. See
stack height of the heatsink on the
board.
Reference Manual
Product Overview
Figure 2-9 on page 17
for the
CoreModule 720
