Chapter 4
•
VGA Palette Snoop [Disabled; Enabled]
•
PERR# Generation [Disabled; Enabled]
•
SERR# Generation [Disabled; Enabled]
PCI Express Device Settings
♦
•
Relaxed Ordering [Disabled; Enabled]
•
Extended Tag [Disabled; Enabled]
•
No Snoop [Disabled; Enabled]
•
Maximum Payload [Auto; 128 Bytes; 256 Bytes; 512 Bytes; 1024 Bytes; 2048 Bytes;
4096 Bytes]
•
Maximum Read Request [Auto; 128 Bytes; 256 Bytes; 512 Bytes; 1024 Bytes; 2048 Bytes;
4096 Bytes]
PCI Express Link Settings
♦
•
Automatic ASPM [Disabled; Auto; Force L0]
WARNING: Enabling ASPM may cause some PCI-E devices to fail
•
Extended Synch [Disabled; Enabled]
•
CPU Configuration
Processor Type
♦
EMT64
♦
Processor Speed
♦
Ratio Status
♦
Actual Ratio
♦
System Bus Speed
♦
Processor Stepping
♦
Microcode Revision
♦
L1 Cache RAM
♦
L2 Cache RAM
♦
Processor Core
♦
Hyper-Threading
♦
Intel SpeedStep [Disabled; Enabled]
♦
Hyper-Threading [Disabled; Enabled]
♦
Execute Disable Bit [Disabled; Enabled]
♦
Limit CPUID Maximum [Disabled; Enabled]
♦
Intel Virtualization [Disabled; Enabled]
♦
C-States [Disabled; Enabled]
♦
Enhanced C1 [Disabled; Enabled]
♦
Enhanced C2 [Disabled; Enabled]
♦
Enhanced C3 [Disabled; Enabled]
♦
Enhanced C4 [Disabled; Enabled]
♦
CoreModule 720
Genuine Intel(R) CPU
Supported
XXXX MHz
XX
XX
XXX MHz
XXXXX
XXX
XX k
XXX k
Single
Supported
Reference Manual
BIOS Setup
39
