System Date
System Date (day of week, mm:dd:yyyy) – This field requires the alpha-numeric entry of the day of
week, day of the month, calendar month, and all 4 digits of the year, indicating the century plus year
(Fri XX/XX/20XX).
System Time
System Time (hh:mm:ss) – This is a 24-hour clock setting in hours, minutes, and seconds.

Advanced BIOS Setup Screen

Main
Advanced
Legacy OpROM Support
Launch PXE OpROM
Launch Storage OpROM
PCI Subsystem Settings
CPU Configuration
GPIO Configuration
Thermal Configuration
SDIO Configuration
USB Configuration
ADM1032 H/W Monitor
Serial Port Console Redirection
Legacy OpROM Support
Launch PXE OpROM [Disabled; Enabled]
Launch Storage OpROM [Disabled; Enabled]
PCI Subsystem Settings
PCI Bus Driver Version V X.XX.XX
PCI ROM Priority [64 PCI Bus Clock; EFI Compatible ROM]
PCI Common Settings
PCI Latency Timer [32 PCI Bus Clocks; 64 PCI Bus Clocks; 96 PCI Bus Clocks; 128 PCI Bus
Clocks; 160 PCI Bus Clocks; 192 PCI Bus Clocks; 224 PCI Bus Clocks; 248 PCI Bus Clocks]
38
[English]
Aptio Setup Utility - Copyright (C) 20XX American Megatrends, Inc.
Chipset
Boot
Version X.XX.XXXX. Copyright (C) 20XX American Megatrends, Inc.

Figure 4-2. Advanced BIOS Setup Screen

Reference Manual
Security
Save & Exit
[Setting Description]
[Disabled]
[Enabled]
:
Select Screen
:
Select Item
Enter : Select
+/- : Change Opt.
F1 :
General Help
F2 :
Previous Values
F3 :
Optimized Defaults
F4 :
Save & Exit
ESC: Exit
BIOS Setup
CoreModule 720
