Chapter 2

Mechanical Specifications

3.250
0.350
0.000
NOTE
All dimensions are given in inches. Pin 1 is shown as a black square on headers and
connectors. Black squares on right-angle headers indicate pin 2 in top-side views and
pin 1 in bottom-side views.
12

Figure 2-9. Mechanical Overview (Top-Side View)

Reference Manual
Product Overview
3.550
3.350
0.200
0.000
CoreModule 740
