Chapter 2

Mechanical Specifications

3.55 (90.17mm)
3.25 (82.55mm)
0.35 (8.89mm)
0.00
0.50 (12.70mm)
NOTE
All dimensions are given in inches. Pin 1 is shown as a black square on headers and
connectors. Black squares on right-angle headers indicate pin 2 in top-side views and
pin 1 in bottom-side views.
CoreModule 745

Figure 2-8. Mechanical Overview (Top Side)

Reference Manual
Product Overview
4.05 (102.87mm)
3.55 (90.17mm)
3.35 (85.09mm)
2.06 (52.45mm)
0.20 (5.08mm)
0.00
0.50 (12.7mm)
15
