Chapter 2

Product Description

The CoreModule 730 SBC is an exceptionally high integration, x86-based, PC compatible system in the
ISM (Industry Standard Module) form factor. This rugged and high quality single-board system contains all
the component subsystems of a PC/AT motherboard plus the equivalent of several PC/AT expansion boards.
The CoreModule 730 includes a comprehensive set of system extensions and enhancements that are
specifically designed for embedded systems. These enhancements ensure fail-safe embedded system
operation, such as a watchdog timer and a temperature monitor. This design meets the size, power
consumption, temperature range, quality, and reliability demands of embedded applications and requires
only a single +5V power source.
Embedded and portable applications benefit from the flexibility of the CoreModule 730, making system
design quick and easy. The CoreModule 730 stacks with ADLINK MiniModule products or other SUMIT-
compliant expansion boards or it can serve as the computing engine in a fully customized application.

Module Features

CPU
Provides x86-based Intel Atom Z530 (1.60GHz) microprocessor
Supports a Front Side Bus (FSB) of 400/533 MHz
Supports IA 32-bit architecture
Provides 32kB Unified Instruction Cache and 24kB Write-Back Data Cache
Provides Low Power and System Management Modes
SCH (System Controller Hub)
Provides integrated Northbridge and Southbridge
Provides CMOS Front Side Bus signaling
Integrates a DDR2 memory controller with a single 64-bit wide interface
Provides three UHCI USB 1.1 controllers
Provides one EHCI USB 2.0 controllers
Memory
Provides standard DDR2 SODIMM socket
Supports 533 MHz Clock Speed
Supports non-ECC, unbuffered memory
Supports +2.5V DDR2, 533MHz RAM up to 2GB DDR2 SODIMM
SUMIT Interface
Provides up to two SUMIT connectors
Supports high-speed serial bus signals
IDE Interface
Provides one IDE channel
Supports two enhanced IDE devices
Supports Ultra ATA
Supports ATAPI and DVD peripherals
Supports IDE native and ATA compatibility modes
4
Reference Manual
Product Overview
CoreModule 730
