Chapter 2

Module Features

•
CPU
Provides 166MHz Intel Atom N450 processor core
♦
DMI (Direct Media Interface) with 1 GB/s of bandwidth in each direction
♦
Enhanced SpeedStep® technology
♦
On die 512-kB, 8-way L2 cache
♦
•
Memory
512MB standard SDRAM soldered on the board
♦
667MHz Clock Speed
♦
•
Interface Buses
PC/104 and PC/104-Plus Interfaces
♦
PC/104 bus speeds up to 8MHz (16-bit ISA Bus)
♦
PC/104-Plus bus speed at 33MHz (32-bit PCI Bus)
♦
PCI 2.2 compliant
♦
•
Utility Interfaces (2)
Provide IDE port
♦
• Supports two enhanced IDE devices
• Supports single master mode
• Supports Ultra DMA 100/66/33 in master mode
• Supports ATAPI and DVD peripherals
• Supports IDE native and ATA compatibility modes
Provide floppy drive port
♦
• Supports one floppy drive
• Supports all standard PC/AT formats: 360kB, 1.2MB, 720kB, 1.44MB, 2.88MB
Provide PS/2 Keyboard and PS/2 Mouse ports
♦
Provide parallel printer port with IEEE standard 1284 protocols, and EPP, ECP outputs
♦
Provide two RS-232 serial ports with full handshaking
♦
Provide two 2.0 USB ports
♦
• Provides one root USB hub
• Provides two USB ports
• Supports USB V2.0
Support external reset switch
♦
Support standard external 8
♦
Support HDD Activity LED
♦
Support external battery for Real Time Clock operation
♦
CoreModule 740
speaker interface
Ω
