Overview

Many parts of the printer, such as the printhead and timing belts, may require
replacement when performing routine maintenance. Some parts may require
replacement because of damage or wear. This section will explain how to
remove and replace these parts.
It is recommended that the service person have the following tools available
before proceeding with the Removal and Replacement procedures.
Phillips Screwdriver #1
Phillips Screwdriver #2
Needle Nose Pliers (Small)
Allen Wrench 1.5 mm
Allen Wrench 2.0 mm
Allen Wrench 2.5 mm
Allen Wrench 3.0 mm
Allen Wrench 4.0 mm
Allen Wrench 1/16 inch
Allen Wrench 5/64 inch
Allen Wrench 3/32 inch (needed for Ribbon Saver option only)
Allen Wrench 3/16 inch
Allen Wrench .050 inch (needed for Ribbon Saver option only)
