Media Hub Assembly (Standard)

ITEM P/N
(T3204)
1 202929–001 202929–001 Assy, Hub Mount
2 202940–001 202940–001 Spring Compression
3 202920–001 202920–001 Washer, Slip clutch
4 202933–001 202933–001 Disk, Slip Clutch
5 202912–001 202912–001 Ring, Retain External 5/8 shaft
6 202939–001 202939–001 Torsion Spring
7 202935–001 202935–001 Hub, Media, 3–inch
8 202914–001 202914–001 Washer, Flat, M4 Black
9 202917–001 202917–001 Screw, 8–32 x 3/8 w/p
10 202934–001 202934–001 Retainer, Media Hub
11 202936–001 202936–001 Screw, Thumb Knob
12 202911–001 202911–001 Screw, Soched, 8–32 x 3/4
13 750057–273 750057–273 Nut, Square, 8–32
14 202941–001 202941–001 Spacer 1.3 OD x 1.00 ID
15 202915–001 202915–001 Washer, Spring Wave, 5/16 ID
Spare Parts
P/N
(T3304)
DESCRIPTION
9–41
