Cover

Removal
1. Turn the printer power switch OFF and unplug the AC power cord from
the AC outlet.
2. Raise the side access cover to a full upright position.
3. Loosen the three screws securing the top edge of the cover and remove
the screw securing the rear of the cover.
4. Loosen the three screws in the bottom left edge of the cover, then lift off
the entire cover.
Removal and Replacement
Figure 7–1
7–3
