Printronix T3204 Maintenance Manual page 119

Media Sensor Assembly
ITEM P/N
(T3204)
1 750057–569 750057–569 Stud Broaching, 1/2" long
2 750057–612 750057–612 Media Sensor Cable Assembly
3 750057–472 750057–472 Top Sensor Guide
4 750057–473 750057–473 Bottom Sensor Guide
5 750057–474 750057–474 4–40 Hex Miniature Nut
6 750057–475 750057–475 Sensor Guide Bracket
7 750057–476 750057–476 4" Tywrap
8 750057–477 750057–477 Sensor Adjust Shaft
9 750057–478 750057–478 Med Sen Shaft Compression Spring
10 750057–479 750057–479 Fiber Washer
11 750057–480 750057–480 Media Sensor Alignment Spring
12 750057–092 750057–092 5/32 Retaining Ring
13 750057–481 750057–481 Support Sensor Bracket
14 750057–482 750057–482 Belt Tensioner Washer
Spare Parts
P/N
(T3304)
DESCRIPTION
9–21
