Thermal Transfer Mechanism (1 of 2)
ITEM P/N
(T3204)
1 750057–289 750057–289 Ribbon Tension Roller
2 750057–470 750057–470 FF–312 Flanged Bearing
3 750057–291 750057–291 Ribbon Supply Assembly
4 750057–484 750057–484 4–40 X .25 SEMS COMB Screw
5 750057–288 750057–288 Ribbon Rewind J Hook
6 750057–294 750057–294 Ribbon Take Up Hub Assembly
7 750057–485 750057–485 .312 Flanged Bearing
8 750057–486 750057–486 Outer Ribbon Roller
9 750057–487 750057–487 Inner Ribbon Roller
10 750057–488 750057–488 3/16 X 5/16 DRS 030 Sleeve Bearing
11 750057–453 750057–453 Washer, Lock #4
12 750057–490 750057–490 Ribbon Guide
13 750057–449 750057–449 Screw, BH 6–32 X .31
14 750057–484 750057–484 Screw, Sems Comb, 4–40 x .25
Spare Parts
P/N
(T3304)
DESCRIPTION
9–23
