Troubleshooting Procedure 6. – No Serial Communications
Step Check Item
1. Ensure that the proper serial communications cable is
connected between the printer and the host. Turn the printer
ON and send a label to the printer. Did the label print?
2. Compare the desired label format with the format produced. Is
the label format correct?
3. Print a configuration label (see page 6–2). Check the label for
the printer's current communications parameters. Do these
parameters match those of the host device?
4. Send a label to the printer with the printer in the hex dump
mode. Setting the printer to the hex dump mode is
accomplished by:
(a) Selecting the hex dump mode from the Secondary
Operator Panel (see the LP+, IGP/PGL, IGP/VGL Setup
Guide , Chapter 3).
(b) Sending a label to the printer after printing an IGP/FGL
configuration label (without turning printer OFF)
Was hex data printed on the label?
6–12
Result Corrective Action
YES Go to Step 2.
NO Go to Step 3.
YES Test complete.
NO Check label programming.
YES Go to Step 4.
NO Properly configure the printer
(see page 3–3).
YES Check the host configuration
and label format.
NO Incorrectly configured or
defective serial
communications cable.
