Printronix T3204 Maintenance Manual page 113

Printhead Mount Assembly
ITEM P/N
(T3204)
1 750057–443 750057–624
2 750057–444 750057–444
3 750057–602 750057–602
4 750057–445 750057–445
5 750057–446 750057–446
6 750057–447 750057–447
7 750057–448 750057–448
8 750057–449 750057–449
9 750057–450 750057–450
10 750057–451 750057–451
11 750057–452 750057–452
12 750057–453 750057–453
13 750057–454 750057–454
14 750057–455 750057–455
15 750057–002 750057–002
16 750057–456 750057–456
Spare Parts
P/N
(T3304)
.1895 X .314 X 3 1 Flange Bearing
.360 X .026 X .75 Compression Spring
.300 X .022 X .88 Compression Spring
.240 X .035 X .56 Compression Spring
6–32 X 3/16 Philips PH EXT SE Screw
DESCRIPTION
Printhead Mounting Plate
Printhead Pivot Bracket
3/16 Set Screw Collar
6–64 X 3/4 SOCHD Screw
6–32 X .31 BH Screw
#8 X .048 Thk Flat Washer
4 X .187 SS SOCHD Screw
#4 Lock Washer
Flat Cable Clamp
.188 DIA Shaft E–Ring
Head Mount Shaft
9–15
