Thermal Transfer Mechanism (2 of 2)
ITEM P/N
(T3204)
1 750057–492 750057–492 Clutch Mounting Hub
2 750057–493 750057–493 Clutch Roller
3 750057–494 750057–494 4–40 X .25 LG Black SEMS Screw
4 750057–495 750057–495 Ribbon Sensor Board Assembly
5 750057–496 750057–496 Insulator
6 750057–497 750057–497 .250 ID Flanged Bushing
7 750057–283 750057–283 1/4 Shaft Collar
8 750057–435 750057–435 Screw, Ext/S, PH, Phil, 10–32 x 3/8
9 202843–001 202843–001 Spacer, Nyl, .257 ID X .500D X .312
10 750057–500 750057–500 44 Teeth Slip Clutch Assembly
11 750057–308 750057–308 4 in–oz Clutch Assembly
12 750057–501 750057–501 Belt Idler Assembly
13 750057–502 750057–502 Insulated Ribbon Sensor Spacer
Spare Parts
P/N
(T3304)
DESCRIPTION
9–25
