Mechanism Assembly (3.0 Inch Media Supply Hub) (2 of 4)
ITEM P/N (T3204)
1 750057–368
2 750057–287
3 750057–369
4 202924–001
5 750057–371
6 750057–372
7 750057–373
8 750057–374
9 750057–375
10 202908–001
11 750057–377
12 750057–378
13 750057–379
14 750057–380
15 750057–381
16 750057–078
17 750057–286
18 750057–281
19* 750057–383
20 202918–001
21 750057–384
22 750057–316
23 750057–387
24 750057–410
25 750057–386
26 750057–218
27 750057–485
28 750057–388
29 750057–389
30 750057–340
31 750057–575
32 750057–089
33 750057–391
34 750057–392
35 750057–393
36 750057–394
37 750057–395
38 750057–396
39 750057–279
40 750057–281
41 750057–284
42 750057–271
43 750057–400
44 750057–280
45 750057–402
46 750057–403
47 750057–280
48 202916–001
(*) Use Platen (Part No. 750057–287) for replacement purposes.
Spare Parts
P/N (T3304)
750057–368
750057–287
750057–369
202924–001
750057–371
750057–372
750057–373
750057–374
750057–375
202908–001
750057–377
750057–378
750057–379
750057–380
750057–381
750057–078
750057–286
750057–281
750057–383
202918–001
750057–384
750057–607
750057–387
750057–410
750057–386
750057–218
750057–485
750057–616
750057–389
750057–604
750057–575
750057–089
750057–391
750057–392
750057–393
750057–394
750057–395
750057–396
750057–279 Screw, Combination Sems (6–32 x .25)
750057–281
750057–284
750057–271
750057–400 Screw, Phil, PH Ext/S (4–40 x 1/4)
750057–280
750057–402
750057–403
750057–280
202916–001
DESCRIPTION
Latch Handle
Platen
Lower Assembly Bearing Plate
Standoff Ext.
Nylon Bearing (.188 3L3–F)
Head Actuate Shaft
Media Idler Roller
Label Edge Guide
Male Hinge
Media Hub Assembly (3 inch)
Rear Panel
Dummy Hub Shaft
Expansion Cartridge Card Guide
Paper Rewind Spacer
Open/Closed Bushing (large)
Open/Closed Bushing (small)
Tear–Off Plate
Screw, Sems Combo, 8–32 x .38
Dummy Platen Shaft
Upper Plate
Bracket (cantilever with holes)
Drive Motor Assembly
Assy, Label Guide
8–32 x 1/2, Phil, PH Ext/S Screw
Media Sensor Knob
Spacer
Bearing, Flanged, .312
Printhead Mount Assembly
Bearing (Nyliner 3/8 ID 6L6f)
Printhead
Bushing, Flanged
3/8, Truarc E–ring,
6–32 x 1/8 Set Screw
Chassis Assembly
Cantilevered Bracket
Ribbon Saver Plate
6–32 x 3/8 Black Screw
Screw, Phil, PH Et/S (6–32 x 3/8)
8–32 x .38, Combination Screw
8–32 x 1/2, Black Screw
1/4 Truarc E–ring
Screw, Combination, (6–32 x .38)
Hinge Plate
Hinge Pin
Screw, Combination, (6–32 x .38)
Screw, Sems 6–32 x 1/4
9–9
