Printronix T3204 Maintenance Manual page 137

Head Lifter Assembly
ITEM P/N
(T3204)
1 750057–538 750057–538 Head lifter Motor Assembly
2 750057–382 750057–382 8–32 KEPS ZP Nut
3 750057–540 750057–540 Head lift Sensor Assembly
4 750057–400 750057–400 4–40 X 1/4 Phillips Pan Head EXT/S Screw
5 750057–542 750057–542 .250 ID Needle Bearing
6 750057–543 750057–543 1/4 Truac 5103 Crescent Retaining Ring
7 750057–544 750057–544 Flanged Bearing
8 750057–545 750057–545 Cam Drive Shaft
9 750057–546 750057–546 3/32 X 5/8 Roll Pin
10 750057–547 750057–547 1–72 X 3/16 SL FH ZP Screw
11 750057–548 750057–548 Encoder Wheel
12 750057–549 750057–549 21 Groove Modified Pulley
13 750057–550 750057–550 128 Groove X .25 .080P Timing Belt
14 750057–410 750057–410 8–32 X 1/2 Phillips PH EXT/S Screw
15 750057–552 750057–552 Ribbon Saver Motor Mounting Bracket
Spare Parts
P/N
(T3304)
DESCRIPTION
9–39
