Operation
SDM-100 "TYPE"
VER: 14.7.4

3.2.1.5 Remote AUPC

Remote AUPC
Status:
BB Loop Back
Status:
3–36
FUNCTION SELECT
REMOTE AUPC

Figure 3-10. Remote AUPC (SDM-100 Operation)

Programs the modem for remote AUPC.
On entry, the current status is displayed. Press [
or OFF. Press [ENTER] to execute the change.
Programs the modem for baseband loopback operation (test mode).
When baseband loopback is turned on, the data and timing signals
are hard-wired (via relays) from the demodulator to the modulator on
the modem side of the interface. The DTE baseband signals are also
looped back from the transmitter data and clock to the receiver data
and clock on the customer side of the interface. This is a
bi-directional loopback of the baseband data. Refer to Figure 3-28 for
a block diagram of baseband loopback operation.
On entry, the current status is displayed. Press [
or OFF. Press [ENTER] to execute the change.
REMOTE AUPC
STATUS:
ON
OFF
Key:
ACCESS TO CONDITIONAL OR
SUBMENU OPTION-DEPENDENT
SDM-100A Satellite Modem
BB LOOP BACK
STATUS:
ON
OFF
Parameter Information
] or [ ] to select ON
↑ ↓
] or [ ] to select ON
↑ ↓
Rev. 0
