Installation
6. Check the equipment against the packing list shipped with the equipment to
7. Refer to Section 2.2 for further system installation instructions.
2.2 System Installation
Install the modem as follows:
1. Mount the modem chassis in the assigned position in the equipment rack. Refer
2. Connect the cables to the appropriate locations on the rear panel. Refer to
3. Before applying power, read and become familiar with Chapter 3.
4. Turn on the power switch (located on the rear panel).
5. Check for proper TX output signal level and spectrum.
6. Check for proper RX input signal level and spectrum.
7. If there are any problems with the installation, refer to Chapter 5 for
2–2
ensure that the shipment is complete.
to Figure 2-1 for an illustration of a typical rack elevation for an M:N system.
Section 2.4 for connector pinouts, placement, and functions.
Verify all jumper settings are correctly set for remote operation. Refer to
Chapter 4 for jumper settings.
troubleshooting the system.
SDM-100A Satellite Modem
Rev. 0
