Comtech EF Data SDM-100A Installation And Operation Manual page 157

SDM-100A Satellite Modem
Set Command:
Modulator Response:
Output
Power Level Status:
Response:
Scrambler Command:
Enable Response:
Status:
Response:
Differential Command:
Encoder Response:
Enable
Status:
Response:
Modulator Command:
Type Response:
Status:
Response:
Modulator Command:
Encoder Response:
Type
Status:
Response:
Transmit Command:
BPSK Data Response:
Ordering
Status:
Response:
Modulator Command:
Spectrum Response:
Rotation
Status:
Response:
Reed- Command:
Solomon Response:
Encoder
Enable Status:
Response:
Modulator Command:
Spectrum Response:
Rotation
Status:
Response:
Rev. 0
<add/MOP_snn.n'cr'
>add/MOP_snn.n'cr''lf']
<add/MOP_'cr'
>add/MOP_snn.n'cr''lf']
<add/SE_xxx'cr'
>add/SE_xxx'cr''lf']
<add/SE_'cr'
>add/SE_xxx'cr''lf']
<add/DENC_xxx'cr'
>add/DENC_xxx'cr''lf']
<add/DENC_'cr'
>add/DENC_xxx'cr''lf']
<add/MT_xxxx'cr'
>add/MT_xxxx'cr''lf']
<add/MT_xxxx'cr'
>add/MT_xxxx'cr''lf']
<add/MET_xxx'cr'
>add/MET_xxx'cr''lf']
<add/MET_xxx'cr'
>add/MET_xxx'cr''lf']
<add/TDA_xxx'cr'
>add/TDA_xxx'cr''lf']
<add/TDA_xxx'cr'
>add/TDA_xxx'cr''lf']
<add/MSR_xxxx'cr'
>add/MSR_xxxx'cr''lf']
<add/MSR_'cr'
>add/MSR_xxxx'cr''lf']
<add/RSEN_xxx'cr'
>add/RSEN_xxx'cr'lf']
<add/RSEN_'cr'
>add/RSEN_xxx'cr'lf']
<add/MSR_xxxx'cr'
>add/MSR_xxxx'cr''lf']
<add/MSR_'cr'
>add/MSR_xxxx'cr''lf']
Where: snn.n = -30.0 to -5.0, in 0.1 steps (nominal range in
dBm).
Notes:
1. The nominal power range is modified relative to the
value specified by the modulator power offset
(MPO_).
2. The MOP_ command will return status only when
local AUPC is enabled.
Where: xxx = ON or OFF.
Where: xxx = ON or OFF.
Where: xxxx = INTL (INTELSAT OPEN NETWORK), EFD
(EF DATA CLOSED NETWORK), CSC (COMSTREAM
CLOSED NETWORK), FDC (FAIRCHILD CLOSED
NETWORK), or SDM51 (SDM51 COMPATIBLE).
Where: xxx = VIT (K-7 VITERBI ENCODER) or SEQ
(SEQUENTIAL ENCODER).
Where: xxx = NRM (STANDARD) or INV (NON-
STANDARD).
Where: xxxx = NRM (normal spectrum) or INV (inverted
spectrum).
Where: xxx = ON or OFF.
Where: xxxx = NRM (normal spectrum) or INV (inverted
spectrum).
Remote Control Operation
A–5
