Remote Control Operation
Interface
Command:
Config
Response:
Status
A–18
<add/ICS_'cr'
>add/ICS_'cr'
TC_xxx'cr'
TCP_xxxx'cr'
RCP_xxxx'cr'
BBL_xxx'cr'
BC_xxx'cr'
IBP_xxx'cr'
IBS_nnnnn'cr'
ADP_xxx'cr'
(Note 1)
SBTR_xxx'cr'
(Note 1)
EMS_x'cr'
(Note 1)
LAW_y'cr'
(Note 1)
HOOK_xxx'cr'
(Note 1)
ISCL_TX_nnn'cr'
(Note 1)
ISCL_RX_nnn'cr'
(Note 1)
RD_xxx'cr'
(Note 1)
SD_xxx'cr'
(Note 1)
RR_xxx'cr'
(Note 1)
DM_xxx'cr'
(Note 1)
ALBJ_xxx'cr'
(Note 1)
RTSM_xxx'cr'
TOBR_nnnnn'cr'
(Note 2)
TCCL_n'cr'
(Note 2)
TCSB_n'cr'
(Note 2)
TOCP_xxxx'cr'
(Note 2)
ROBR_nnnnn'cr'
(Note 2)
RCCL_n'cr'
(Note 2)
ROCP_xxxx'cr'
(Note 2)
LPC_xxx'cr'
(Note 2)
NOMP_snn.n'cr'
(Note 3)
MINP_snn.n'cr'
(Note 3)
MAXP_snn.n'cr'
(Note 3)
LCL_xxxx'cr'
(Note 3)
RCL_xxxx'cr'
(Note 3)
ENSP_nn.n'cr'
(Note 3)
MAXT_n.n'cr'
(Note 3)
OCT_xxxxx'cr'
(Note 4)
TCT_xxxxx'cr'
(Note 4)
ISSD_xxx'cr'
(Note 4)
ISRS_xxx'cr'
(Note 4)
ISMC_xxx'cr'
(Note 4)
ISTT_xxx'cr'
(Note 4)
ISRD_xxx'cr'
(Note 4)
ISRR_xxx'cr'
(Note 4)
ISDM_xxx'cr'
(Note 4)
ISCS_xxx'cr'
(Note 4)
ISRT_xxx'cr'
(Note 4)
ISST_xxx'cr''lf']
(Note 4)
Transmit Clock (Source)
Transmit Clock Phase
Receive Clock Phase
Baseband Loop Back
Buffer Clock (Source)
Interface Buffer Programming
Interface Buffer Size
Interface ADPCM Programming
Interface Subscriber/Trunk Emulation
Interface RD Signal
Interface Transmit Encoding Law
Interface Off Hook Alert Enable
Interface Transmit Service Channel Level
Interface Receive Service Channel Level
Interface RD Signal
Interface SD Signal
Interface RR Signal
Interface DM Signal
Interface Analog Loopback Jumper Status
RTS TX-IF Control Mode
ASYNC Transmit Overhead Baud Rate
ASYNC Transmit Channel Character Length
ASYNC Transmit Channel Stop Bits
ASYNC Transmit Overhead Channel Parity
ASYNC Receive Overhead Baud Rate
ASYNC Receive Channel Character Length
ASYNC Receive Overhead Channel Parity
AUPC Local Enable
AUPC Nominal Power Value
AUPC Minimum Power Value
AUPC Maximum Power Value
AUPC Local Carrier Loss
AUPC Remote Carrier Loss
AUPC E
/N
Target Set Point
b
0
AUPC Max. Tracking Rate
ASYNC Overhead Communications Type
Terrestrial Communications Type
ASYNC Interface SD Signal
ASYNC Interface RS Signal
ASYNC Interface MC Signal
ASYNC Interface TT Signal
ASYNC Interface RD Signal
ASYNC Interface RR Signal
ASYNC Interface DM Signal
ASYNC Interface CS Signal
ASYNC Interface RT Signal
ASYNC Interface ST Signal
The Interface configuration status command causes a block of
data to be returned by the addressed modem. The block
reflects the current configuration of the interface.
Notes:
1. Status only returned when ADPCM board is installed.
2. Status only returned when ASYNC option is enabled.
3. Status only returned when AUPC option is enabled.
4. Status only returned when ASYNC board is installed.
SDM-100A Satellite Modem
Rev. 0
