Figure 3-14. Utility System (Sdm-100 Operation) - Comtech EF Data SDM-100A Installation And Operation Manual

Operation
SDM-100 "TYPE"
VER: 14.7.4
TIME: HH:MM:SS AM/PM
DATE: MM/DD/YY
Current time and date.
OPERATION MODE
DUPLEX
RECEIVE ONLY
TRANSMIT ONLY
FPGA FIRMWARE
(Status Only)
FW/NNNNNN-DDR
FPGA FIRMWARE
MM/DD/YY
Key:
ACCESS TO
SUBMENU
3–48
FUNCTION SELECT
UTILITY
REMOTE BAUD RATE
110 4800
150 9600
300 19200
600 EVEN
1200 ODD
2400 NONE
LAMP TEST??
Press [ENTER]
DSP FIRMWARE
(Status Only)
FW/NNNNN-DDR
DSP FERMWARE
MM/DD/YY
CONDITIONAL OR
Parameter Information
OPTION-DEPENDENT

Figure 3-14. Utility System (SDM-100 Operation)

SDM-100A Satellite Modem
UTILITY
SYSTEM
REMOTE ADDRESS
X
X = 1 to 255
DISPLAY CONTRAST
LEVEL: X
X = 0 to
MASTER RESET
HARD/SOFT
Initiating a hard reset resets
modem and places the default
configuration settings in the
memory. Initiating a soft reset
will reset the modem
but saves the current firmware
configuration settings.
M&C MODULE FW
(Status Only)
FW/NNNNNN-DDR
MM/DD/YY
Rev. 0
