SDM-100A Satellite Modem
AUPC Command:
Minimum Response:
Power Limit
Status:
Response:
AUPC E /N Command:
b 0
Target Set Response:
Point
Status:
Response:
AUPC Command:
Maximum Response:
Tracking
Rate Status:
Response:
AUPC Local Command:
Carrier Loss Response:
Action
Status:
Response:
AUPC Command:
Remote Response:
Carrier Loss
Action Status:
Response:
Remote
Modem
AUPC
Commands
Remote Command:
AUPC Response:
Enable
Status:
Response:
Remote Command:
Interface Response:
Baseband
Loop Back Status:
Response:
Rev. 0
<add/MINP_snn.n'cr'
>add/MINP_snn.n'cr''lf']
<add/MINP_'cr'
>add/MINP_snn.n'cr''lf']
<add/ENSP_nn.n'cr'
>add/ENSP_nn.n'cr''lf']
<add/ENSP_'cr'
>add/ENSP_nn.n'cr''lf']
<add/MAXT_n.n'cr'
>add/MAXT_n.n'cr''lf']
<add/MAXT_'cr'
>add/MAXT_n.n'cr''lf']
<add/LCL_xxxx'cr'
>add/LCL_xxxx'cr''lf']
<add/LCL_'cr'
>add/LCL_xxxx'cr''lf']
<add/RCL_xxxx'cr'
>add/RCL_xxxx'cr''lf']
<add/RCL_'cr'
>add/RCL_xxxx'cr''lf']
<add/RPC_xxx'cr'
>add/RPC_xxx'cr''lf']
<add/RPC_'cr'
>add/RPC_xxx'cr''lf']
<add/RBBL_xxx'cr'
>add/RBBL_xxx'cr''lf']
<add/RBBL_'cr'
>add/RBBL_xxx'cr''lf']
Where: snn.n = -30.0 to -5.0, in 0.1 steps (nominal range in
dBm).
Note: The nominal power range is modified relative to the value
specified by the modulator power offset (MPO_).
Where: nn.n = 3.2 to 16.0, in 0.1 increments (E
Where: n.n = 0.5 to 6.0, in 0.5 increments (max. tracking rate in
dBm/minute).
Where: xxxx = HOLD, NOM, or MAX (power level setting when
local carrier loss).
Where: xxxx = HOLD, NOM, or MAX (power level setting when
remote carrier loss).
Notes:
1. Always wait 3 seconds between consecutive remote
modem command/status polls.
2. If Local AUPC is not enabled, status commands will
return last known condition. They will also request
status from the remote modem. This allows a second
request to return proper status.
Where: xxx = ON, OFF, or UNK (remote AUPC enable).
Where: xxx = ON, OFF, or UNK (remote baseband loop back
enable).
Remote Control Operation
/N in dB).
b 0
A–13
