Remote Control Operation

A.3.4 System

Time Of Command:
Day Response:
Status:
Response:
Date Command:
Response:
Status:
Response:
Remote Command:
Response:
Clear Command:
Stored Response:
Faults
Modem Command:
Operation Response:
Mode
Status:
Response:
RTS TX-IF Command:
Control Response:
Mode
Status:
Response:

A.3.5 AUPC

AUPC Local Command:
Enable Response:
Status:
Response:
AUPC Command:
Nominal Response:
Power Level
Status:
Response:
AUPC Command:
Maximum Response:
Power Limit
Status:
Response:
A–12
<add/TIME_hh:mmxx'cr'
>add/TIME_hh:mmxx'cr''lf']
<add/TIME_'cr'
>add/TIME_hh:mmxx'cr''lf']
<add/DATE_mm/dd/yy'cr'
>add/DATE_mm/dd/yy'cr''lf']
<add/DATE_'cr'
>add/DATE_mm/dd/yy'cr''lf']
<add/REM_'cr'
>add/REM_'cr''lf']
<add/CLSF_'cr'
>add/CLSF_'cr''lf']
<add/MOM_xxxxxxx'cr'
>add/MOM_xxxxxxx'cr''lf']
<add/MOM_'cr'
>add/MOM_xxxxxxx'cr''lf']
<add/RTSM_xxx'cr'
>add/RTSM_xxx'cr''lf']
<add/RTSM_'cr'
>add/RTSM_xxx'cr''lf']
<add/LPC_xxx'cr'
>add/LPC_xxx'cr''lf']
<add/LPC_'cr'
>add/LPC_xxx'cr''lf']
<add/NOMP_snn.n'cr'
>add/NOMP_snn.n'cr''lf']
<add/NOMP_'cr'
>add/NOMP_snn.n'cr''lf']
<add/MAXP_snn.n'cr'
>add/MAXP_snn.n'cr''lf']
<add/MAXP_'cr'
>add/MAXP_snn.n'cr''lf']
Where:
hh = 1 to 12 (hours).
mm = 00 to 59 (minutes).
xx = AM or PM.
Where:
mm = 1 to 12 (month).
dd = 1 to 31 (day).
yy = 00 to 99 (year).
This command configures the modem for remote operation.
The SDM100A will respond to any status request at any time.
However, the SDM100A must be in 'Remote Mode' to change
configuration parameters.
This command is used to clear all stored faults logged by the
SDM100A.
Where: xxxxxxx = TX_ONLY, RX_ONLY, or DUPLEX.
This command configures the modem for simplex or duplex
operation modes. When transmit only mode is selected receive
faults are inhibited and when receive only mode is selected
transmit faults are inhibited.
Where: xxx = ON or OFF.
This command configures the modem for the RTS TX-IF
control mode. If "ON" is selected, the TX-IF output will only be
turned on if the incoming RTS signal is asserted (also the TX-
IF output has to be programmed ON and no major modulator
faults are present). If "OFF" is selected, the TX-IF output will
operate normal ignoring the RTS signal.
Where: xxx = ON or OFF.
Note: When programmed ON, the MOP (Modulator Output
Power) command is not allowed, only MOP status is allowed.
Where: snn.n = -30.0 to -5.0, in 0.1 steps (nominal range in
dBm).
Note: The nominal power range is modified relative to the value
specified by the modulator power offset (MPO_).
Where: snn.n = -30.0 to -5.0, in 0.1 steps (nominal range in
dBm).
Note: The nominal power range is modified relative to the value
specified by the modulator power offset (MPO_).
SDM-100A Satellite Modem
Rev. 0
