Operation
SDM-100 "TYPE"
VER: 14.7.4
MODULATOR X
HH:MM:SS/MM-DD-YY
IF SYNTHESIZER
DATA CLOCK SYN
I CHANNEL ^
Q CHANNEL ^
AGC LEVEL
MODULE
COMMON X
HH:MM:SS/MM-DD-YY
BATTERY/CLOCK
-12 VOLT SUPPLY
+12 VOLT SUPPLY
+5 VOLT SUPPLY
CONTROLLER
INTERFACE MODULE
3–34
FUNCTION SELECT
STORED
FLTS/ALMS
DEMODULATOR X
HH:MM:SS/MM-DD-YY
CARRIER DETECT^
IF SYNTHESIZER
I CHANNEL^
Q CHANNEL^
DESCRAMBLER^
BER THRESHOLD^
MODULE
UNAVAL SECONDS X
HH:MM:SS/MM-DD-YY
X = 0 TO 9

Figure 3-9. Stored FLTS/ALMS (SDM-100 Operation)

TX INTERFACE X
HH:MM:SS/MM-DD-YY
TX AUDIO CLIP ^
TX CLK ACTIVITY
CLEAR??
STORED FAULTS
CLEAR ??
YES
Key:
ACCESS TO CONDITIONAL OR
SUBMENU OPTION-DEPENDENT
SDM-100A Satellite Modem
RX INTERFACE X
HH:MM:SS/MM-DD-YY
BUFFER CLK ACT ^
BUFFER UNDERFLOW ^
BUFFER OVERFLOW ^
RX AUDIO CLIP ^
DEMUX LOCK ^
REMOTE OFF HOOK ^
Notes:
1. X = 0 to 9.
2. Stored time/date will alternate.
HH:MM:SS, MM-DD-YY, or no fault.
3, ^ = Disabled in Burst Mode.
Parameter Information
Rev. 0
