Remote Control Operation

A.3.3 Interface

Transmit Command:
Clock Response:
Status:
Response:
Transmit Command:
Clock Response:
Phase
Status:
Response:
Buffer Clock Command:
Response:
Status:
Response:
Receive Command:
Clock Response:
Phase
Status:
Response:
Baseband Command:
Loop Back Response:
Status:
Response:
Interface
Buffer Size
Interface Command:
Buffer Size Response:
(Bit Format)
Status:
Response:
Interface Command:
Buffer Size Response:
(Milli-
second Status:
Format) Response:
Interface Command:
Buffer Response:
Center
Interface Command:
Buffer Response:
Program
Status:
Response:
Interface Command:
ADPCM Response:
Program
Status:
Response:
A–8
<add/TC_xxx'cr'
>add/TC_xxx'cr''lf']
<add/TC_'cr'
>add/TC_xxx'cr''lf']
<add/TCP_xxxx'cr'
>add/TCP_xxxx'cr''lf']
<add/TCP_'cr'
>add/TCP_xxxx'cr''lf']
<add/BC_xxx'cr'
>add/BC_xxx'cr''lf']
<add/BC_'cr'
>add/BC_xxx'cr''lf']
<add/RCP_xxxx'cr'
>add/RCP_xxxx'cr''lf']
<add/RCP_'cr'
>add/RCP_xxxx'cr''lf']
<add/BBL_xxx'cr'
>add/BBL_xxx'cr''lf']
<add/BBL_'cr'
>add/BBL_xxx'cr''lf']
<add/IBS_nnnnn'cr'
>add/IBS_nnnnn'cr''lf']
<add/IBS_'cr'
>add/IBS_nnnnn'cr''lf']
<add/IBS_nn'cr'
>add/IBS_nn'cr''lf']
<add/IBS_'cr'
>add/IBS_nn'cr''lf']
<add/IBC_'cr'
>add/IBC_'cr''lf']
<add/IBP_xxx'cr'
>add/IBP_xxx'cr''lf']
<add/IBP_'cr'
>add/IBP_xxx'cr''lf']
<add/ADP_xxx'cr'
>add/ADP_xxx'cr''lf']
<add/ADP_'cr'
>add/ADP_xxx'cr''lf']
Where: xxx = INT (internal SCT clock), EXT (external TX
terrestrial clock), or SAT (receive satellite clock).
Where: xxxx = NRM (normal clock phasing), INV (inverted
clock phasing), or AUTO (automatic clock phasing).
Where: xxx = INT (internal SCT clock), EXT (external TX
terrestrial clock), SAT (receive satellite clock), or REF (external
reference clock).
Where: xxxx = NRM (normal clock phasing) or INV (inverted
clock phasing).
Where: xxx = ON or OFF.
Buffer size programming is supported in two formats; bits, or
milli-seconds. The selected format must be chosen using the
buffer programming command (IBP_).
Where: nnnnn = 64 to 65536, in 16 bit increments.
Where: nn = 0 to 50 (buffer size in milli-seconds).
Where: xxx = BITS or MS (milli-seconds).
Where: xxx = ON or OFF.
Note: Only valid when ADPCM board is installed.
SDM-100A Satellite Modem
Rev. 0
