Operation
M&C Module
Firmware
FPGA Firmware
DSP Firmware
Master Reset
3–50
Displays M&C module firmware version.
Upon entry, the date of release of this firmware will be displayed. This
is a status window only.
Displays firmware version of the Field Programmable Gate Array.
Upon entry, the date of release of this firmware will be displayed. This
is a status window only.
Displays the firmware version installed in the Digital Signal Processor
(DSP).
Upon entry, the date of release of this firmware will be displayed. This
is a status window only.
Master reset function.
CAUTION
When a hard reset is initiated, the modem hardware is reset, and
all default configuration settings will be installed. When a soft
reset is initialized, the modem hardware will be reset, but the
initial firmware configuration settings will be saved.
Press [ENTER] once to access Soft. Press [
between Hard and Soft until the desired type is visible. Press
[ENTER]. If Soft has been selected, press [ENTER] again to reset the
modem. If Hard is selected, press [
press [ENTER].
SDM-100A Satellite Modem
] or [
] to alternate
↑
↓
] until the cursor is on YES, and
→
Rev. 0
