Figure 3-5. Configuration Interface (Sdm-100 Operation) - Comtech EF Data SDM-100A Installation And Operation Manual

Operation
SDM-100 "TYPE"
VER: 14.7.4
TX CLOCK SOURCE
TX TERRESTRIAL
RX (SATELLITE)
SCT (INTERNAL)
B-BAND LOOP BACK
OFF
ON
ASYNC INTERFACE
ON
OFF
(ASYNC only)
ASYNC RX
LENGTH
5 to 8 bits
(ASYNC only)

Figure 3-5. Configuration Interface (SDM-100 Operation)

3–16
FUNCTION SELECT
CONFIGURATION
TX CLOCK PHASE
AUTO
NORMAL
INVERT
BUFFER SIZE
64 to 65536 Bits
in 16-bit steps or
Bypass = 0 bits.
0 to 50 ms
ASYNC TX
BAUD
150 to 2400 bits
(ASYNC only)
ASYNC TX
PARITY
ODD
EVEN
NONE
(ASYNC only)
CONFIGURATION
INTERFACE
BUFFER CLOCK
RX (SATELLITE)
SCT (INTERNAL)
EXT. REFERENCE
TX TERRESTRIAL
BUFFER CENTER
YES/NO
ASYNC RX
BAUD
150 to 2400 bits
(ASYNC only)
ASYNC RX
PARITY
ODD
EVEN
NONE
(ASYNC only)
Key:
ACCESS TO CONDITIONAL OR
SUBMENU OPTION-DEPENDENT
SDM-100A Satellite Modem
RX CLOCK PHASE
NORMAL
INVERT
LOOP TIMING
ON
OFF
(ASYNC only)
ASYNC TX
LENGTH
5 to 8 bits
(ASYNC only)
B
Parameter Information
Rev. 0
