SDM-100A Satellite Modem
Rev. 0
p64 = xxxx, where 'xxxx' is the currently programmed
parity.
Parameter 65 (p65): ASYNC Overhead Communications
Type (ref. "OCT_" command).
p65 = n, where 'n' is '0' (RS232) or '1' (RS485).
Parameter 66 (p66): Interface Wire Type (ref. "IWt_"
command).
p66 = n, where 'n' is '2' (2-Wire) or '4' (4-Wire).
Parameter 67 (p67): Terrestrial Communications Type (ref.
"TCT_" command).
p67 = n, where 'n' is '0' (RS422) or '1' (V.35).
Parameter 68 (p68):
ASYNC Interface SD Signal (ref.
"ISD_" command).
p68 = n, where 'n' is '0' (NORMAL) or '1' (INVERT).
Parameter 69 (p69):
ASYNC Interface RS Signal (ref.
"ISD_" command).
p69 = n, where 'n' is '0' (NORMAL) or '1' (INVERT).
Parameter 70 (p70):
ASYNC Interface MC Signal (ref.
"IMC_" command).
p70 = n, where 'n' is '0' (NORMAL) or '1' (INVERT).
Parameter 71 (p71):ASYNC Interface TT Signal (ref. "ITT_"
command).
p71 = n, where 'n' is '0' (NORMAL) or '1' (INVERT).
Parameter 72 (p72):
ASYNC Interface RD Signal (ref.
"IRD_" command).
p72 = n, where 'n' is '0' (NORMAL) or '1' (INVERT).
Parameter 73 (p73):
ASYNC Interface RR Signal (ref.
"IRR_" command).
p73 = n, where 'n' is '0' (NORMAL) or '1' (INVERT).
Parameter 74 (p74):
ASYNC Interface DM Signal (ref.
"IDM_" command).
p74 = n, where 'n' is '0' (NORMAL) or '1' (INVERT).
Parameter 75 (p75):
ASYNC Interface CS Signal (ref.
"ICS_" command).
p75 = n, where 'n' is '0' (NORMAL) or '1' (INVERT).
Parameter 76 (p76):
ASYNC Interface RT Signal (ref.
"IRT_" command).
p76 = n, where 'n' is '0' (NORMAL) or '1' (INVERT).
Parameter 77 (p77):ASYNC Interface ST Signal (ref. "IST_"
command).
p77 = n, where 'n' is '0' (NORMAL) or '1' (INVERT).
Parameter 78 (p78): Modulator Spectrum Rotation "MSR_
command).
p78 = n, where 'n' is '0' (NORMAL) or '1' (INVERT).
Parameter 79 (p79): Demodulator Spectrum Rotation
"DSR_ command).
p79 = n, where 'n' is '0' (NORMAL) or '1' (INVERT).
Parameter 80 (p80): Reed Solomon Encoder Enable (ref
"RSEN_ command).
p80 = n, where 'n' is '0' (off) or '1' (on).
Parameter 81 (p81): Reed-Solomon Decoder Enable (ref
"RSDE_ command).
p81 = n, where 'n' is '0' (OFF) or '1' (CORR_OFF).
Notes:
1. Status only returned when ADPCM board is
installed.
2.
Status only returned when ASYNC board is
installed.
3.
Status only returned when ASYNC option is
enabled.
4.
For any parameter other than the last parameter
that is not returned, a comma (",") will be returned.
Remote Control Operation
(Note 2)
(Note 2)
(Note 2)
(Note 2)
(Note 2)
(Note 2)
(Note 2)
(Note 2)
(Note 2)
(Note 2)
(Note 2)
(Note 2)
(Note 2)
A–25
