SDM-100A Satellite Modem

3.2.1.6 Utility

The utility functions are divided into five user categories, and provide access to the
following Utility menus:
•
•
•
•
•
These menus provide a means to:
•
•
•
After entering the "UTILITY" functions level, press [
menu desired, and press [ENTER]. Press [
interest.
Note: Changes in the Utility menu may cause changes in other front panel menus.
CAUTION
Rev. 0
MODULATOR
DEMODULATOR
INTERFACE
SYSTEM
MODEM TYPE
Set the time and date of the modem real time clock.
Test the front panel optical indicators.
Choose filtering types, code rates, decoder types, TX and RX fault enables,
modem type, and overhead type.
The UTILITY "FACTORY SET-UP" menu is for EFData service personnel
only. Unauthorized access may cause the modem to operate incorrectly.
] or [ ] to select the "UTILITY"
← →
] or [ ] to select the utility function of
← →
Operation
3–37
