Figure 3-25. Utility System (Type 1 Operation) - Comtech EF Data SDM-100A Installation And Operation Manual

Operation
SDM-100 "TYPE"
VER: 14.7.4
TIME: HH:MM:SS AM/PM
DATE: MM/DD/YY
Current time and date.
DISPLAY CONTRAST
LEVEL: X
X = 0 to 100
MASTER RESET
HARD/SOFT
Initiating a hard reset
the modem and places the
default configuration settings
in the memory. Initiating
soft reset will reset the
modem hardware, but saves
the current firmware
configuration settings.
3–74
FUNCTION SELECT
UTILITY
REMOTE BAUD RATE
110 4800
150 9600
300 19200
600 EVEN
1200 ODD
2400 NONE
M&C MODULE FW
(Status Only)
FW/NNNNNN-DDR
MM/DD/YY
Key:
ACCESS TO
SUBMENU

Figure 3-25. Utility System (Type 1 Operation)

UTILITY
SYSTEM
REMOTE ADDRESS
X
X = 1 to 255
FPGA FIRMWARE
(Status Only)
FW/NNNNNN-DDR
FPGA FIRMWARE
MM/DD/YY
CONDITIONAL OR
Parameter Information
OPTION-DEPENDENT
SDM-100A Satellite Modem
LAMP TEST??
Press [ENTER]
DSP FIRMWARE
(Status Only)
FW/NNNNN-DDR
DSP FIRMWARE
MM/DD/YY
Rev. 0
