SDM-100A Satellite Modem

3.2.2.5.4 Utility System Functions: Type 1 Operation

Time/Date
Remote Baud Rate
Remote Address
Lamp Test??
Display Contrast Level
Rev. 0
Time of day and date set/display function.
The current time and date in the modem memory are
displayed when selected. To set the modem time and/or
date, press [ENTER]. Press [
flashing cursor over the parameter to be changed. Press
[ ] or [ ] to change the parameter to the desired value.
↑ ↓
Once the parameters are displayed as desired, press
[ENTER] to set the time and date.
The current baud rate and the parity selection of the
modem are displayed.
To set the modem baud rate and/or parity, press
[ENTER], and use [ ] or [
←
cursor over the parameter to be changed. Press [
to change the parameter to the desired value. Once the
parameters are displayed as desired, press [ENTER] to
set the baud rate and parity. The baud rate can be set
from 110 to 19200. The parity can be set to even, odd, or
none.
The current modem address is displayed (1 to 255).
To set the remote address, press [ENTER]. Press [
[ ] to change the parameter to the desired value. Press
↓
[ENTER] to execute the change.
Lamp test function verifies the function of all front panel
indicators. Press [ENTER] to turn on all of the front panel
indicators for three seconds.
Set the contrast setting of the front panel display.
Press [ENTER] in order to change the contrast of the front
panel display. Press [ ] or [
↑
the number at the flashing cursor from 0 to 100. Press
[ENTER] to execute the change.
Operation
] or [ ] to position the
← →
] to position the flashing
→
] or [
↑
↑
] to increment or decrement
↓
]
↓
] or
3–75
