Specifications; Physical; Environmental; Type Tests - GE Multinet 4 Instruction Manual

OVERVIEW
1.2

Specifications

1.2.1

Physical

1.2.2

Environmental

1.2.3

Type Tests

Standard Name
Electrostatic Discharge: Air and Direct
Electrostatic Discharge: Air and Direct
Electrical Fast Transient / Burst Immunity
Electrical Fast Transient / Burst Immunity
Power Transients (high repetition)
1–4
The following sections provide detailed information about the physical, electronic, and
industrial specifications of the Multinet4.
The physical dimensions and weight of the Multinet4 are defined in the table below.
Height: 1.75 inches (4.45 cm)
Width: 9.5 inches (24.13 cm)
Depth: 9.5 inches (24.13 cm)
Weight: 5.0 lbs (2.3 kg)
The environmental specifications of the Multinet4 are defined in the table below.
Table 1–2: Environmental Specifications
Operating Temperature:
UL / cUL /CE Safety Rating
Storage Temperature:
Operating Humidity:
.
EN/IEC61000-4-2:1995
IEEE C37.90.3:2001
EN/IEC61000-4-4:2004
IEEE C37.90.1:2002
NEMA TS2 2.1.6.1:2003
MULTINET4 MULTI-PORT SERIAL SERVER & MANAGED SWITCH – INSTRUCTION MANUAL
Table 1–1: Physical Specifications
50°C (122°F) maximum
-40°C to 85°C (-40°F to 185°F)
95% non-condensing
Standard Number:Date
code
CHAPTER 1: OVERVIEW
Severity levels Tested
Level 4 - 8Kv contact,15Kv air
8Kv contact, 15Kv air
Level 4 - 4KV @2.5Khz
Class 4 - 4KV for all port
300V,2500W
