CHAPTER 4: SYSTEM ADMINISTRATION
MULTINET4 MULTI-PORT SERIAL SERVER & MANAGED SWITCH – INSTRUCTION MANUAL
The figure below depicts an Administration: Software Upgrade window after a successful
upgrade.
FIGURE 4–20: Administration: Software Upgrade
The table below describes the parameters you can view and configure in the Software
Upgrade screen.
Field Name
File: To install a new software image:
The system checks to make sure that the uploaded software is
valid for this hardware and that it appears to be a good image
(not corrupt). If it is valid, then:
Table 4–20: Software Upgrade
Field Value
Install Form
1. Browse to a file on you local system, or enter the full
path name of a configuration file.
Upload
2. Click .
1. The filename is added to the Existing Images Table
and is given the designation "new" in the Use column.
2. The status reported in the Software Upgrade process
state table is changed to "READY TO UPGRADE."
