CHAPTER 1: OVERVIEW
1.4.2
Features Summary
Connectivity
Power Options
Mounting Options
Serial Port Management
MULTINET4 MULTI-PORT SERIAL SERVER & MANAGED SWITCH – INSTRUCTION MANUAL
The table below summarizes the hardware features of the Multinet4.
Table 1–10: Hardware Features Summary
Feature
The table below summarizes the features of the Multinet4.
Table 1–11: Software Features Summary
Feature
Details
• 4 Ethernet ports
2 100FX multi/single mode Fiber, ST, SC, and
—
LC
2 10/100 BaseT, RJ45 Auto-Negotiation and
—
Auto-MDIX
OR
4 10/100 BaseT, RJ45 Auto-Negotiation and
—
Auto-MDIX
• 4 programmable RS232/485 serial ports
• High (90 -250 VAC or VDC)
• Low (24-48 VDC)
• Panel
• DIN-rail
• 19" rack
• 19" rack reverse
Details
• Up to 16 serial profiles
• Serial data statistics
• RS-232 (Full/Half) & RS-485 (Full/Half) supported via software
selection
• Data rates from 1200 baud to 115200 bps
• 7 or 8 data bits
• 1, 1.5, or 2 stop bits
• Even, Odd, or No Parity
• Hardware and Software (XON/XOFF) Flow Control
• Packetization options
Forward on specific character, idle time, or
—
packet size
Turnaround timer
—
OVERVIEW
1–13
