OVERVIEW
1–8
LED Name Condition
S1 – S4 Green
(Serial Ports)
Off
Flashing
E1 – E4 Green
(Ethernet Ports)
Off
Flashing
Console Green
Off
Flashing
Alarm Off
Red
Orange
Green
MULTINET4 MULTI-PORT SERIAL SERVER & MANAGED SWITCH – INSTRUCTION MANUAL
Table 1–5: Indicators
Indication
Port is connected to an active serial device.
Port is down.
Data is passing through the port.
Port is connected to an active Ethernet device.
Port is down.
Data is passing through the port.
Connected to an active local terminal.
Not connected.
Data is passing through the port.
No power is applied to unit.
Reset state: System is not loaded
System is being booted.
Normal operation.
CHAPTER 1: OVERVIEW
